Description
Electronics Focussing:
- The system uses advanced electronic LED management systems for operation.
- The system performs electronic focusing that controls the light field diameter through a procedure which does not require mechanical operations. The system enables large spot size operation while maintaining light intensity through its movement mechanism.
Laminar Flow Friendly:
Light head design enables the best possible laminar air flow on the surgical site. Minimizing contamination of bacteria.
Additional information
| SPECIFICATION | DETAILS |
|---|---|
| Max Light Intensity at 1m (Lux) | 1,60,000 Lux |
| No. of LED’s | 23 |
| LED Life Time | 60,000 Hrs |
| Lamp Head Diameter | 600 mm |
| Dimming Range | 25-100% |
| Field Diameter (Focus) | 100-300 |
| Endoscopic Mode | 30% Dimming |
| R9 (Red Colour) | >95 (Optional) |
| Touch Screen Panel | Optional |
| HD Camera | Optional |
| CRI (Ra) | >92 |
| Colour Temperature in Kelvin | 3000-5000K |
| Input Voltage | AC 220-230V / 50-60 Hz |
